• Size:2"
• Interface mode:male thread
• Measurement(cm):610*325*138mm
• Feature:Easy to Install
• Color:Black
• Maximum flow rate:30 m^3/h
• Filter grade:75/120 /150mesh
• Brand:DFSGG
• Type:Other Watering & Irrigation
• Material:plastic
• Place of Origin:CN;FUJ
• Brand Name:DFSGG
• Model Number:DFS-2NR/M

2 inch water filtration screen filter

2inch Screen Filters offer quick and easy manual cleaning without flow interruption. To clean, just open the flush valve and turn the handle to rotate the dirt collector. The combination of rotation and linear movement scans and cleans the whole internal screen surface. Water flow to the field is not interrupted during the cleaning process. A stainless steel screen provides strength and long life durability.

Product Advantages

·Easy to clean – no need to manually disassemble, clean screen and reassemble the filter.

·Water flow to the field is not interrupted during cleaning.

·Corrosion-proof high density polypropylene will not rust or corrode like metal filters.

·Operates efficiently at varied flow rates.

Applications

·Primary filter on well water with small amounts of sand

·Primary filter for center pivots

·Reservoir water with small amounts of algae

·Back-up filter for:

oMedia filter batteries

oSand separators

Pic	Item No.	Description	Size	Interface mode	Element	Filter grade	Maximum working pressure	Maximum flow rate
	DFS-2NR/M	Screen filter	2"	Thread,Thread,Thread	Screen	75/120 /150mesh	10Kg/cm2	30m3/h
