- Size:2"
- Interface mode:male thread
- Measurement(cm):610*325*138mm
- Feature:Easy to Install
- Color:Black
- Maximum flow rate:30 m^3/h
- Filter grade:75/120/150mesh
- Brand:DFShou
- Type:Other Watering & Irrigation
- Material:plastic
- Place of Origin:CN;FUJ
- Model Number:DFS-2NV/M
2 inch screen filter for waters
Features
lMicron-precise level filtration
lResistant to chemical products with durable
lEasy cleaning & easy maintenance
lVarious outlet size & outlook design to meet multiple applications
lLow cost with excellent performance
Product Usage
lIrrigation System Water Filtration: Prevent Irrigation System Blockage, Improve Irrigation Efficiency
lWater treatment: water treatment for different purposes; water from industrial, civil, urban construction, etc. used for irrigation systems at Gore Stadium, parks, etc.; desalination equipment for reverse osmosis filtration
| Pic | Item No. | Description | Size | Interface mode | Element | Filter grade | Maximum working pressure | Maximum flow rate |
 | DFS-2NV/M | 2"standard screen filter | 2" | Bayonet,Bayonet,Thread |  | 75/120/150mesh | 10kg/cm2 | 30m3/h |
| Screen | ||||||||
Description | Item No. | A | B | C | E | M | H(mm) | W(mm) | X(mm) |
Screen filter | DFS-2NR/M | 2"male thread | 2"male thread | 2"male thread | 3/4"female thread | 1/4"female thread | 610 | 325 | 138 |
DFS-2NV/M | 2"bayonet | 2"bayonet | 2"male thread |
Packing: Kraft paper box or according to clients' requirements.
