• Product name:farm irrigation systems
• M/Roll:300
• Feature:Easy to Install
• Color:black
• Application:Irrigation
• Diameter:Cusomers' Request
• Roll length:500-1000-1500-2000-2500m/roll
• Certification:ISO9001
• Type:Other Watering & Irrigation
• Material:plastic
• Place of Origin:CN;FUJ
• Brand Name:DFSGG
• Model Number:LDP1610025

Features

lExtruded with the highest quality polyethylene resin, containing less than 2% carbon black, strict quality control with excellent anti-aging and anti-freeze cracking, long service life

lSmooth inner wall, small loss

lGood flexibility, easy coiling, suitable for terrain changes, easy installation

lAvailable in a variety of sizes, roll lengths and pressure ratings

lMainly used in main and branch pipelines in irrigation systems.

lExecutive standard: GB/T23241-2009

Product Usage

lThe products are mainly used for waterhead adjustment of agricultural irrigation systems, installation pipes for drippers and micro sprinklers, irrigation and drainage systems, water conservancy and hydropower, chemicals, and factory cooling and so on .

l16,20,25: Usually used as final pipe for installing drippers, drip arrows and micro sprinklers

l32, 40 and more : Usually used as branch pipes and trunks

l5-8 :Usually used as a dripper and micro sprinkler, etc.

Technical indicators

lElongation at break% ≥350

lHydraulic test≥3 times working pressure

lOxidation induction time ,Min≥20

Note:We can produce according to the customer's required diameter and roll length

Pic	Item No.	Description	Unit	Packing M/Roll	Measurement (Cm)	G.W (Kgs)
	LDP1610025	Dn16,1.0mm,0.25Mpa	M	500	Dn80*30	23
	LDP161204	Dn16,1.2mm,0.4Mpa	M	500	Dn80*30	27
	LDP2012025	Dn20,1.2mm,0.25Mpa	M	200	Dn70*30	14
	LDP201504	Dn20,1.5mm,0.4Mpa	M	200	Dn75*30	17
	LDP2514025	Dn25,1.4mm,0.25Mpa	M	200	Dn95*30	20
	LDP251904	Dn25,1.9mm,0.4Mpa	M	200	Dn100*30	27
	LDP3216025	Dn32,1.6mm,0.25Mpa	M	200	Dn115*38	30
	LDP322404	Dn32,2.4mm,0.4Mpa	M	200	Dn115*38	41
	LDP633604	Dn63,3.6mm,0.4Mpa	M	100	160*45CM	67
